C-gun spot welder(For Steel car body)
AC-7C
Brief: AC-7C is for professional car body workshops. It allows spot welding 2 faces with a pneumatic clamp; welding monopoint 1 face with a gun for small repairs, hammered, patchwork and nails poses, pins, discs, rivets. Moreover, it supplys steel and stainless steel welding with 12 functions, we set the recommendation current and time value. AC-7C features:
1.Automatic over-heated protection function;
2.Repair functions for different steel auto body include stainless steel and other materials ;
3.One side welding and both sides welding can be chosen;
4.Heat,meson,vertical pulling,spot welding,flatten,waveform line,whorl post,triangle shim etc welding;
5.Possess gas filtrate and regulate function;
6.Unique cable rack,have front-back flexible function,Can turn 360 degree;
7.Triangle shim direct spot welding repair;
8.LCD digital chinese and english graph display;
9.Large puller and waveform welding;
10.Equipped infinitely current regulate,for any options.
Technical parameter | ||
Model | AC-7C | |
Power supply | 2ph 400V or 1ph 230V 50/60Hz | |
Max current | 10000A | |
Normal power at 50% | 12KVA | |
Max power | 60KVA | |
Thermal class | F | |
Protection degree | IP21 | |
Max air pressure | 1.0Mpa(10Bar) | |
Output voltage | 2-13V | |
Welding depth | 1.0+2.0mm (1 face) | |
Welding depth | 3.0+3.0mm (2 faces) | |
Cables | 2*3m*150mm2 (2 faces) | |
Cables | 2*2.5m*75mm2 (1 face) | |
Packaging Size | 66*78*130cm(0.67CBM) | |
Gross Weight | 145kg | |
Packing | Polywood | |
Certification | ISO CE | |
Code | 117000 | |
MOQ | 1 set |
