INVERTER SPOT WELDING SYSTEM with USB 16000A
ACS12-3GUN
Brife:ACS12-3GUN is ideal for car-body works and serial productions with USB data storage. With double pistons cylinder, customisation of any stored spot welding programs; Operation with pneumatic clamp, manual and studder welding; Senses the voltage and auto-compensates for the power source; Control and regulation of all the steps of the spot welding process; Microprocessor controlled, three-phases, inverter (MFDC 2000Hz) resistance welding; Automatic control of the spot welding current(16000A) continuous and pulse operation; High efficiency and productivity improved in comparison with the traditional resistance welding systems; Over 200 pre-set programs according to the kind and thickness of the material used and to the kind of clamp chosen; High quality and aesthetic of the
spot on all kinds of high resistance steels, HSS, AHSS, galvanized steels and stainless steels. Features:
1.Spot Welding Gun: Single Sided Gun, C-Gun, X -Gun
2.Welding Pulse: Single Pulse, Double welded, Pulse welding, No spark welding.
3.Display system: 8"LCD Display
4.Functions: Air pressure, Voltage testing, Offset Voltage, Temperature sencer monitoring, Lack of phase,Over-current, Thermal protections, cooling fluid monitoring, USB data storage.
5.Cooling System: Water cooled C-gun/X-gun/Arm sets/Transformer/Radiator
| Technical parameter | |
| Model | ACS12-3 |
| Power supply | 3ph 380-430V 50/60Hz |
| Max current | 16000A |
| Normal power at 50% | 28KVA |
| Max power | 78KVA |
| Thermal class | H |
| Protection degree | IP21 |
| Max electrode power 8bar | X-Gun: 345daN |
| C-Gun: 350daN(600Lb) | |
| No-load voltage | 6-26V |
| Welding depth | 2.0+2.5mm (1 face) |
| Welding depth | 4.0+4.0mm (2 faces) |
| 2.0+2.0+2.0mm (2 faces) | |
| Cables | 2*3m*150mm2 (2 faces) |
| Cables | 2*2.5m*75mm2 (1 face) |
| Packaging Size | 80*73*126cm(0.74CBM) |
| Gross Weight | 200kg |
| Packing | Polywood |
| Certification | ISO CE |
